General: Toilet compartments shall be Type BE-______ (CS-Ceiling Stile; or FS-Floor Stile; or FF-Full Flush; or FC-Floor to Ceiling) as manufactured by American Sanitary Partition Corporation, Ocoee, FL 34761.
Materials: All steel shall be Galvanized. Bonderized. Zinc Coating to be .00015" thick each side. Panels over 48" wide shall be 20 gauge. Panels 48" wide and smaller and doors shall be 22 gauge. Headrail shall be 6063-T5 aluminum etched and anodized. FF and FC stiles shall be 20 gauge. CS and FS stiles shall be 18 gauge.
Construction: Stiles, panels and doors shall be of veneer steel construction. Laminated under pressure to a honeycomb core of correct dimension producing a stile unit of not less than 1 1/4" thick and panel and door units of not less than 1" thick. The edges of the stile. panel and door sheets shall be formed to interlock with each other, producing a rigid two-piece unit. All corners shall be welded and ground smooth. Stile, panel and door units shall be reinforced internally and pre-pierced for the application of fittings and hardware. Panels shall be attached to stiles with 3 concealed tension cleats.
Fittings: All wall brackets shall be cast alloy non-ferrous metal. All brackets are chrome plated and adjustable to keep panels and stiles clear from walls. Stile cover bases shall be 3" high, of No. 304 stainless steel.                                                                                                                                                                 Finish: A powder-coated paint over zinc-coated Bonderite-treated steel, baked on at 350 degrees to provide maximum protection and durability. Finish to be one color or one combination of two-colors selected from American Sanitary's standard color chart. Color charts available on request.
Hardware: Doors shall be equipped with "Trouble-Proof" hinge set. Each hinge set shall consist of cast non-ferrous metal hinge brackets. All hinge brackets are chrome plated. The top pivot shall be recessed into the edge of the door 2 1/2" below the top. Heavy steel pin operating in a "Zytel" nylon cams which permit setting of the door at any desired position when door is not latched. Slide latch, combination bumper and keepers and coat hooks shall be of cast metal which are all chrome plated. All hardware except coat hooks shall be through bolted. One way theft proof screws and fasteners shall be provided for all hardware. Stainless Steel & Institutional hardware available on request.
